Honda VT500C Shadow 1984

Model :Honda VT 500C Shadow

Year:1984

Engine: Liquid cooled, four stroke, 52°V-twin, SOHC, 3 valves per cylinder.

Capacity: 491 / Bore x Stroke 71 x 62 mm / Compression Ratio 10.5:1

Induction: 2x 32mm Keihin carbs

Ignition / Starting: Electronic / electrical

Max Power: 47.5 hp 34.6 kW @ 9000 rpm

Max Torque: 42 Nm @ 7000 rpm

Transmission / Drive: 6 Speed / shaft

Front Suspension: Air assisted telescopic forks.

Rear Suspension: Pivoted fork dual adjustable shocks

Front Brakes: Single disc 2 piston caliper

Rear Brakes: Drum

Front Tyre: 100/90-18

Rear Tyre: 130/90-16

Dry-Weight: 180 kg

Fuel Capacity: 12.5 Litres

Syntaksen i rammenummret i EU-modellerne er iflg.

http://kleinjung.de/techdata/ og reservedelsfiche'en:

Regulær, udroslet udgave:

PC08-20..../83 - til D, F, CH, I og EU generelt,

PC08-21..../'84 - kun til N

PC08-22..../'85 - ingen Eu

PC08-23..../'86 - kun til A

Droslet (27hk) udgave:

PC08-30...../'83 - til D

Utfra dette er min nr 4 i Norge.
